what size pex is used in rvs

by Una Nikolaus Published 3 years ago Updated 3 years ago

In RVs, manufacturers typically use translucent non-colored PEX for all plumbing runs. Further, two sizes are used, 3/8-inch and ½-inch. These are the standard size because the outside diameter of the tubing is about 1/8-inch greater than the called-for size.Dec 7, 2016

Full Answer

What size PEX is used for RV plumbing?

PEX tubing in homes is color-coded for hot and cold. In RVs, manufacturers typically use translucent non-colored PEX for all plumbing runs. Further, two sizes are used, 3/8-inch and ½-inch.

Why are RV water lines made of PEX?

That’s because the water lines in most RVs are plastic “PEX” pipe. They are not buried inside walls and are usually accessible for easy repair. PEX stands for cross-linked polyethylene. Typically, this pipe is connected using a special tool and metal fittings that can complicate the fixing procedure for RVers.

How many fixtures can you put on a PEX pipe?

Ans. 1/2 inch PEX pipe usually has up to 4 fixtures. 3/4 pipes can have up to 14 fixtures, and 1-inch pipe can have up to 30 fixture units. 2. How far apart should PEX hangers be? Ans. Proper hangers must support long runs of PEX pipe.

Can you use 3/8 inch PEX for hot water?

At one hardware store, bulk 3/8-inch may set you back 50 cents/foot. Additionally, PEX is ideal for both cold and hot water (some up to 200 degrees) plumbing. Typically, the rating is on the tubing itself. Chlorinated water is not an issue in terms of tubing or health safety.

What size PEX water lines are in an RV?

Regarding standard sizes for PEX, the 1/2 inch is the biggest PEX used in RVs, while the 3/8 inch is a slightly smaller size PEX. However, most RVs use 1/2 inch PEX tubing or piping. 1/2 inch PEX tubing or piping is used because it has the highest flow rate.

Is RV PEX the same as House PEX?

Is RV PEX the Same as House PEX? Yes, it is. The PEX used in an RV is “basic” PEX.

What type of water lines are used in RVs?

There are two types of water lines: RV copper line, these are usually found in older model vehicles. RV plastic line, which is the material of choice for modern vehicles. (PEX as discussed above)

What size PEX tubing should I use?

In general, the greater the distance from the manifold to the fixture, the wider the PEX tubing should be. A 3/8-inch line is sufficient for lengths up to 250 feet; 1/2-inch line will deliver adequate water pressure up to 350 feet; and 3/4-inch tubing is necessary to run a 500-foot line.

What type of PEX is used in RVs?

In RVs, manufacturers typically use translucent non-colored PEX for all plumbing runs. Further, two sizes are used, 3/8-inch and ½-inch. These are the standard size because the outside diameter of the tubing is about 1/8-inch greater than the called-for size. Also, PEX is inexpensive.

Can you use PEX in a camper?

Pex tubing is lightweight, but durable to withstand the pressurized water coming into the RV unit. If you have an older RV with the old water line system, you can easily replace the water lines using Pex tubing.

What size is GREY PEX pipe?

1/2”Polybutylene pipes are usually 1/2” or 1” in diameter and marked with the code “PB2110.” Inside the house, polybutylene piping is typically grey and can often be found close to water heaters, sinks and toilets, as well as inside walls and along ceilings in basements.

Can you use sharkbite fittings in an RV?

0:3713:19HOW TO INSTALL A SHARKBITE IN YOUR RV PLUMBING / RV LIFEYouTubeStart of suggested clipEnd of suggested clipAnd it's a lot easier to work with and it's a little bit more freeze resistant than copper was soMoreAnd it's a lot easier to work with and it's a little bit more freeze resistant than copper was so that's why so many RVs now have pecs the cool thing about pax plumbing is it's really easy to fix.

What size water line is in a mobile home?

Your water supply lines are the smaller pipes (3/8″ to 1″) that come into the home. They are usually either copper or Pex.

What is the difference between Type A and Type B PEX pipe?

Bottom line, PEX A is more resistant to burst pressure than PEX B. PEX A's expansive material can handle up to 500 PSI, which makes it reliable in extremely cold temperatures. Since PEX B is a more rigid material, it will not hold up as well in similar situations.

Is PEX A or B better?

Kink-Resistance - PEX-A has the greatest resistance, PEX-B the lowest. You should never install kinked pipe. Bursting Pressure – Always check the tubing for maximum temperature and pressure ratings. Remember, the pressure ratings decrease as the temperature of the water increases.

Can I use blue PEX for hot water?

Color-Coded: Red PEX pipes can be used for hot water supply lines, blue PEX for cold water supply, and white for either hot or cold. These colors are just for your convenience. Plumbing code does not require the pipe color to match the type of water supply.

How many fixtures are on a 1/2 PEX water line?

1/2 inch PEX pipe usually has up to 4 fixtures. 3/4 pipes can have up to 14 fixtures and 1-inch pipe can have up to 30 fixture units.

How far apart should PEX hangers be?

Long runs of PEX pipe must be supported by proper hangers. It is usually recommended to fasten the tubing at every 32 inches when running it alongs...

Does PEX need expansion loops?

Always remember that PEX expands and contracts as a response to the surrounding temperature. For every 10 F of temperature change, the PEX pipe len...

What is the maximum distance between hangers for 1/2 PEX?

Maximum hanger spacing is 6' for ½" and ¾" pipe and 8' for 1" and larger full-length pipe segments with PEX-a Pipe Support.

Is PEX safe for drinking water?

PEX pipes are 100% safe to be used for drinking water. A few types of PEX-pipes may cause prolonged undesirable taste and odor if the water remains...

Does PEX piping affect the water pressure?

No. The PEX piping doesn't slow or affect the water pressure anyway.

Why PEX Pipe Is Best For Van Conversions

PEX pipe offers 4 distinct advantages for those building a camper van and/or RV.

What Size PEX Do Campers Use?

You can easily find PEX pipes that have an inner diameter of ½” and ¾”. But for camper vans and RVs, the ½” pipes will be sufficient. The ¾” pipes are primarily for main water lines that enter a residential home.

PEX Fittings

In order to build a complete plumbing system you’ll need to pair PEX tubing with several types of metal fittings. These fittings allow you to:

How To Crimp PEX Pipes

To crimp the copper ring over the PEX tube and fitting, you’ll need a specific crimping tool.

Can PEX Pipes Resist Freezing Temperatures?

PEX pipes are proven to be more flexible and durable than their PVC counterparts. This makes them more resistant to bursting when water begins to freeze in sub-zero temperatures.

Conclusion

We hope this post convinced you that going with PEX tubing is the best option for your camper van plumbing build. Of course, PEX is just one of the many components in building a complete system for your sink or shower.

What is the difference between blue and red Pex tubing?

The blue tubes are used for cold water systems and the red is used for hot water systems. Because the Pex tubing is easily installed, you should be able to add additional features to your RV, including extra faucets, a refrigerator with an ice maker, exterior shower and/or a winterizing kit.

Why do you need extra tubing for RV water lines?

Because it is so easy to replace these water lines, it is recommended to have extra tubing with when traveling. That way, should the line get cracked or damaged you are prepared to replace the damaged section. Pex tubing is lightweight, but durable to withstand the pressurized water coming into the RV unit. If you have an older RV ...

What is PEX in RV water supply?

They are not buried inside walls and are usually accessible for easy repair. PEX stands for cross-linked polyethylene. Typically, this pipe is connected using a special tool ...

What is the standard size of PEX tubing?

Also, PEX is inexpensive. At one hardware store, bulk 3/8-inch may set you back 50 cents/foot.

How much does a 3/8 inch coupler cost?

Quick-Connect fittings: Made by Watts, these are a little more costly. A 3/8-inch coupler for joining two pieces of tubing is around $4.00. Using these fittings in a cramped area is much easier.

Can you cut PEX tubing?

While working on water lines, you just need a tool to cut the PEX tubing itself. You can use a utility knife, but a tubing cutter designed for PEX ensures a clean, even edge. This is also a requirement for a leak-proof connection. These cutters are less than $10.

Is PEX tubing safe for hot water?

Additionally, PEX is ideal for both cold and hot water (some up to 200 degrees) plumbing. Typically, the rating is on the tubing itself. Chlorinated water is not an issue in terms of tubing or health safety.
