what is the verge of a roof

What is the verge of a roof?

• Decking (or sheathing) Usually made from 1⁄2-inch plywood, the decking closes and reinforces the roof structure and provides a nailbed for the shingles.
• Roof edge (or eaves edge) All the boards running along the edge of the roof or eaves.
• Attic.
• Saddle.
• Ridge.
• Valley.
• Underlay membrane.
• Eaves membrane.

Full Answer

What is a verge on a roof?

The 'verge' refers to the outer ends of your roof above the gable end (the wall above which two verges meet). Traditionally, these areas at the edge of your roof are fixed with mortar in order to prevent water ingress and pests such as birds nesting in your roof. Click to see full answer. Regarding this, what is a dry verge on a roof?

What is the edge of a roof called?

The 'verge' refers to the outer ends of your roof above the gable end (the wall above which two verges meet). Traditionally, these areas at the edge of your roof are fixed with mortar in order to prevent water ingress and pests such as birds nesting in your roof.

What part of the roof goes over the wall?

The roof itself goes over the wall and any part that is in line or overhangs the outside face of the wall in known as the verge.

Can You Dry fix a verge on a roof?

Tiles on the verge are often mortared to prevent rain and wind from getting underneath the tiles. Dry fix options for verges are also available from a number of manufacturers. When the mortar on a verge crumbles or disappears then there is a risk of leaks from water being blown into the roof space.

What is the verge of a house?

The verge connects the eaves to the ridge and is frequently referred to as the front of the house. When looking at a house, the focus is on the verge. It therefore frequently has a very sophisticated design or is highly decorated.

What is the verge overhang?

Verge tiles should overhang the building fabric by between 38 and 50mm. Less than 38mm and watermarks will show down the face of the wall. Greater than 50mm and end tiles in each row will become unstable due to the overhang and buffeting on the underside and the suction on the upper side as wind blows over it.

How do you repair a roof verge?

Small cracks in the mortar of the verge can be quickly and easily fixed by using a roof and gutter sealant. This is injected into the crack with the applicator and allowed to dry before being painted over (if required). You can buy sealant in several colours to match the mortar if it is to be left unpainted.

What is the edge of a tiled roof called?

Eaves. The eaves of a roof is its lowest horizontal edge. The eaves may terminate flush with the outer face of the wall, in which case it is known as a 'flush eaves'.

What is a verge in building terms?

Verge. The edge of a sloping roof which overhangs a gable.

What is the minimum overhang for a roof?

There is no true standard size for overhangs, but typical overhangs that are used for protection from rainfall are 16-18 inches wide. Overhangs wanted for shading should be minimally 24 inches.

How do you replace a dry verge?

0:336:51How To Install Redland's Ambi Dry Verge - YouTubeYouTubeStart of suggested clipEnd of suggested clipWe just pop the units over the side of the tile here it's close down to the fascia as we can get itMoreWe just pop the units over the side of the tile here it's close down to the fascia as we can get it and then we'll see there a screw holes in the side there which we can fix it in to the roof.

What is the cement on the edge of a roof called?

How I Cement Roof Tiles. Welcome to Daniel's Roof and our guide to securing and cementing roof tiles. The tiles which are cemented to the roof edge of many homes are often called verge or gable tiles and the condition of this cement can deteriorate over time.

How do you repoint verge tiles?

0:0016:06Cementing the verges to complete a tiled roof. The old boy method...YouTubeStart of suggested clipEnd of suggested clipWelcome to building the bud to die we're going to be putting cement in the verges. In there so it'sMoreWelcome to building the bud to die we're going to be putting cement in the verges. In there so it's all watertight we're going to put a fillet along the top i'm going to do the other side of this.

What are the sides of a roof called?

Roof edge (or eaves edge) All the boards running along the edge of the roof or eaves. Also known as a fascia.

What is the end of a roof called?

EavesEaves. The lower edge of a roof (usually overhanging beyond the edge of the house).

What's a roof purlin?

In steel construction, the term purlin typically refers to roof framing members that span parallel to the building eave, and support the roof decking or sheeting. The purlins are in turn supported by rafters or walls.

What is the eaves of a roof?

The eaves of a roof is its lowest horizontal edge. The eaves may terminate flush with the outer face of the wall, in which case it is known as a 'flush eaves'. It may also project out beyond the external wall, with a soffit below.

What is a roof made of?

A roof is made up of a system of products working together and it’s important to be clear on the terminology, especially since the parts of a roof can be referred to in different ways.

Where do rafters rise?

Sometimes referred to as common rafters or spars, these inclined lengths of timber rise from the eaves at the bottom of the roof to the ridge apex at the top. Rafters support a pitched roof covering.

What does "verge" mean in the dictionary?

Definition of verge (Entry 3 of 3) intransitive verb. 1 a of the sun : to move or tend toward the horizon : sink. b : to move or extend in some direction or toward some condition verging to a hasty decline — Edward Gibbon. 2 : to be in transition or change.

What is a verge in a sentence?

Noun the suspect was on the verge of confessing when the officers realized that he hadn't been read his rights the southern verge of the national park.

What is the roof verge?

A roof verge is the outer edge of the very top section of a roof and is designed to prevent moisture, insects, and animals from getting into the roof. The verge begins where the outer shingles or roofing tiles end and the roof meets the gable, which is the ridge formed by the 2 sides of the roof.

How to make a ridge on a roof?

1. Place a ridge end cap at the top of the last 2 verge pieces. At the top of the verge on the roof, or the apex, there will be a gap between the last 2 verge pieces. The point of the top of the roof will run between them to form a ridge.

How do I secure a verge to a batten?

At the top edge of the verge piece is a hole that lies flat against the outer edge of the batten. Take a roofing nail and center it inside the hole . Use a hammer to carefully strike the head of the nail and drive it into the batten to secure the verge piece to it.

Where do I hang a verge tile?

The verge piece will hang over the lip of the roof. Line it up so it’s flush against the fascia, or the outer edge of the roof. Hold the verge tile in place with your hands. The starter insert rests flat against the fascia which is the board attached to the underside of the outer edge of the roof.

How to install a starter verge?

1. Position a verge piece against the top of the starter verge. Take a dry verge piece and align the edges on the underside of it with the edges on top of the starter verge. Fit the verge piece onto the starter verge so flush against it and there isn’t any space between the 2 pieces.

What is a traditional verge?

A traditional verge is built on the fascia. Verges can also be undercloaked when a fibre cement board projects beyond the fascia and the tile verge is mortared to this. Modern houses are often built with dry verge systems. Whilst these do look neat they may look out of place on a traditional roof.

Why do you mortar a verge?

Tiles on the verge are often mortared to prevent rain and wind from getting underneath the tiles. Dry fix options for verges are also available from a number of manufacturers. When the mortar on a verge crumbles or disappears then there is a risk of leaks from water being blown into the roof space. The roof verge will need to be rebedded ...

Can you repoint a slate verge without removing the tiles?

Repointing a tile verge without removing the tiles and rebedding them on a mortar base is pretty much a waste of time. Mortar can be coloured to match the roof covering.
