Some of the forklift capacity ratings for common types of forklifts are:
| Forklift Type | Rated Capacity Range |
| Forklift Type Electric 3-Wheelers | Rated Capacity Range 3,000 lb. — 5,000 l ... |
| Forklift Type Electric 4-Wheelers | Rated Capacity Range 3,000 lb. — 12,000 ... |
| Forklift Type Electric Stand-Up Riders | Rated Capacity Range 3,000 lb. — 5,000 l ... |
| Forklift Type Electric Reach Trucks | Rated Capacity Range 3,000 lb. — 4,500 l ... |
Are rated capacity and maximum capacity of a forklift the same?
OSHA requires “only loads within the rated capacity of a truck shall be handled.” It’s easy to think the rated capacity is the same as maximum capacity, but it’s not that simple. The basic capacity of a forklift is based on the model.
How do you find the capacity of a forklift?
You can find the rated capacity of a forklift on its data plate. OSHA requires “only loads within the rated capacity of a truck shall be handled.” It’s easy to think the rated capacity is the same as maximum capacity, but it’s not that simple. The basic capacity of a forklift is based on the model.
What is the maximum weight a forklift can handle?
For example, if you have a 10,000 lb. capacity forklift with an attachment that is only capable of handling 5,000 lbs., your maximum rated capacity for the combination of these two is 5,000 lbs., which is what will be listed on your data plate.
What is the length of a forklift's raced capacity?
This length is the recommended distance from the rear of the forks to the center of mass of the load. So, a forklift's raced capacity might be given as 6000 lbs @ 24 inches load center of mass.
What does rated capacity mean on a forklift?
A forklift's rated load capacity is the maximum weight in kilograms that a forklift can safely lift and transport at a specified load centre distance in millimetres. This rated load capacity is listed on the forklifts name plate or load capacity data plate.
Where is the rating capacity on a forklift?
As a general rule, load center is 24" from the face of the forks (the center point of standard 48” x 48” pallet). Forklift capacities range from about 3,000 lbs up to more than 70,000+ lbs. You can find the rated capacity of a forklift on its data plate.
How much can a 8000 lb forklift lift?
This dual fuel forklift has a maximum lift capacity of 8,000 lbs. and a maximum lift height of 187”.
How much can a 30k forklift lift?
This diesel fuel forklift has a maximum lift capacity of 33,000 lbs., a maximum lift height of 148”, and hydraulic power. The maximum power source is 164 HP diesel fuel.
How do you read a forklift capacity plate?
Max Lifting Height: The maximum lift height based on load centers. Load Center: This number indicates how far forward from the mast the balancing point of the load is. The further it is from the center, the less weight it can withstand. Back Tilt: The maximum degree of back tilt (tilting the load towards the operator).
How do you read a load capacity chart?
1:015:59How to Read a Load Chart - YouTubeYouTubeStart of suggested clipEnd of suggested clipCenter so the load center is indicated by half the distance of the fork. And that's really importantMoreCenter so the load center is indicated by half the distance of the fork. And that's really important because it changes how much weight you're going to be able to put on the machine.
What can lift 8000 pounds?
4-wheel lifts – One extra wheel improves the lift's ability to carry weight. While 3-wheel lifts can move around 4,800 lbs., 4-wheel lifts are capable of carrying nearly 8,000 lbs! Counterbalance forklifts – These are some of the most common types of forklifts, and they can hoist up to 5,500 lbs.
How much does a unloaded 5000 capacity lift truck weigh?
Typically, a 5k forklift will weigh 5000 lbs.
How is load center calculated?
Essentially, a load centre is the middle of a forklift load, when measured front to back. This is calculated by measuring whatever it is you need to lift, then dividing by two (assuming an even load). So, if you have a load that weighs 1,700kg and is 1,000mm long, we can determine that the load centre is 500mm.
How much can a 10000 pound forklift lift?
Equipment Overview Connected to a telehandler, the forklift gives the operator horizontal positioning ability with its 55 ft telescopic boom. With a carrying capacity of up to 10,000 lbs, the telescopic forklift is typically used for large-scale industrial and construction material handling projects.
How many kg can a forklift lift?
The maximum weight these machines can safely lift is 2,500kg. Three wheel – These are primarily pallet lifts used in environments where space is limited. Their load capacity is 2,200kg.
How high can forklifts lift?
Most standard forklifts can reach heights between 10 and 15 feet, but special forklifts like the telehandler can lift as high as 55 feet depending on the telehandler size you select.
What Is The Maximum Carrying Capacity of My Forklift to A Given Lift height?
The load carrying capacity of a forklift is indicated on the capacity data plate or name plate and should be found affixed to the forklift in a pro...
Forklift Attachments Change The Capacity of The Lift Truck
A forklift attachment includes anything that is attached to the front carriage of a forklift or is attached to an attachment on the forklift. A typ...
Capacity Decreases The Higher The Forklift Lifts
Lift height or maximum fork height (MFH) has a significant effect on a forklift’s load carrying capacity, and forklifts with high masts will have a...
If The Length of The Load Is Longer, Lifting Capacity Is Reduced
Because a forklift is using leverage to lift a load, any condition that adds weight to the front of the forklift and causes the load center (LC or...
Load Center Also Effects Carrying Capacity
Small changes in load center can also greatly affect the carrying capacity. Consider the capacity of the same 5,000 lb forklift with 48” forks and...
Where to Check Your Lift Capacity
The main thing to consider is that every forklift has a legible capacity plate that accurately reflects the attachment configuration being used at...
Why is a forklift used to lift a load?
Because a forklift is using leverage to lift a load, any condition that adds weight to the front of the forklift and causes the load center (LC or CG) of the load to be moved further away from the forklift will contribute to a reduction in the residual carrying capacity of the machine .
What is a forklift attachment?
A forklift attachment includes anything that is attached to the front carriage of a forklift or is attached to an attachment on the forklift. A typical forklift attachment configuration might include a hang-on side shifter and two forks.
What is load center?
Load center typically refers to the horizontal distance to the load CG and is typically half the length of the load for symmetrical objects.
How much weight can a forklift lift?
It is a common misconception is that a forklift with a maximum rated lifting capacity of 5,000 lbs. can lift any 5,000 lb. load.
What is plated forklift?
Forklifts are plated as standard for the worst case scenario, which includes all of these factors. The ability to move the load further away from the forklift’s center of gravity by lifting, tilting, or performing a function like side shift can all affect a forklift’s maximum capacity.
How does uneven distribution affect forklifts?
Since the load center also depends on the load’s weight distribution, an unevenly distributed load can also reduce the overall lifting capacity of the forklift.
Does a cushion tire increase truck capacity?
A cushion tire versus a solid or air-filled pneumatic tire, for example, can have an effect on capacity. Wide tread and dual tire configurations can also increase a truck’s overall capacity due to the wider stance increasing the size of the forklift’s stability triangle.
Do forklifts need data plates?
It is important to remember that both ANSI and OSHA require data plates for each attachment and written approval from the forklift manufacturer for any modifications or alterations that may affect the capacity, stability, or safe operation of the forklift.
Why is it important to determine forklift load capacity?
Correctly establishing forklift load capacity is critical. This is because not getting it right can result in numerous problems. Included among these are injuries to employees that can be major. It can also lead to significant financial troubles.
What is the center of gravity of a forklift?
When at rest, on level ground, the forklift’s center of gravity is within the stability triangle. But if the forklift is put in motion, or sits on a sloping surface, it’s center of gravity shifts.
Why do you need a forklift attachment?
Adding a forklift attachment reduces the lifting capacity of the truck due to the additional weight of the attachment itself and because an attachment typically moves the truck’s load center farther forward. As the center of gravity moves forward, the maximum load weight must decrease to prevent tip-overs.
What is the fulcrum of a forklift?
The fulcrum is the central pivot point of a seesaw. The front axle is the fulcrum of the forklift where the counterweight and the load find balance. One of the hardest things for lift truck operators to learn during training is how to maintain their center of gravity within their stability triangle. A forklift has a three-point suspension system.
