What is free haul and overhaul? 207.1 DESCRIPTION. Overhaul is authorized hauling beyond the free-haul limit. The free-haul limit is the specified distance the excavated material is hauled without additional. compensation.
What is the difference between free haul and overhaul volume?
The area enclosed within the segment and the mass haul line represents the free haul volume. Further, perpendicular lines from the ends of the segment are dropped so that they touch the balance line. The areas enclosed within these lines, the balance line, and the mass haul line represent the overhaul volume.
What is the free haul limit in construction?
The free-haul limit is the specified distance the excavated material is hauled without additional. compensation. Unless otherwise provided in the Contract Documents, the free-haul limit is 2,000 feet. Click to see full answer. Accordingly, what is free haul? Definition of free haul.
What is an overhaul in construction?
Similarly, you may ask, what is overhaul in construction? Overhaul involves (1) partial or complete disassembly of the item, (2) inspection to detect damaged, defective, or worn parts, (3) repair or replacement of such parts, and (4) reassembly, testing, and trial-run prior to returning the item to its full operating level.
How far can you haul with overhaul?
Overhaul is authorized hauling beyond the free-haul limit. The free-haul limit is the specified distance the excavated material is hauled without additional. compensation. Unless otherwise provided in the Contract Documents, the free-haul limit is 2,000 feet. Click to see full answer.
What is overhaul in construction?
To overhaul is to completely renovate, making major changes in order to repair. A few shutters and a new coat of paint won't come close to fixing that old, boarded-up house — it needs a complete overhaul.
What is the free haul distance?
Free Haul Distance (F.H.D) is the specified distance wherein an excavated material will be. hauled without additional cost (there is a fixed cost for each m. 3. excavation hauling and. dumping).
What is overhaul in excavation?
Overhaul shall consist of the transportation of excavated material from roadway and borrow excavation, from channel excavation, and from excavation for structures, a distance in excess of the free haul limit specified for the particular kind of excavation involved.
What is overhaul earthwork?
Overhaul: Is the number of cubic meters (yards) of overhauled material multiplied by. the overhaul distance, this distance is measured between the center of gravity of cut and. fill (i.e. m. 3. *station or yd.
How do you determine overhaul?
How to Calculate Overhaul Cost of EquipmentIdentify the make, model and serial number of the equipment. ... Determine the present realizable salvage value of the equipment. ... Request quotes for the cost to overhaul the equipment. ... Average the quotes for the cost to overhaul the equipment.More items...
How do you find an overhaul?
The overhaul distance is determined by deducting the free-haul distance from the distance between the center of gravity of the remaining mass of excavation and the remaining mass of embankment.
What is haul distance?
The distance measured along the center line or most direct practical route between the center of the mass of excavation and the center of mass of the fill as finally placed. It is the distance material is moved.
How do you calculate free haul volume?
From grade points, a segment the length of the free haul distance, which is parallel to the balance line, is dropped so that the ends of the segment just touch the mass haul line . The area enclosed within the segment and the mass haul line represents the free haul volume.
How is average haul calculated?
Average haul is the area of the mass diagram representing the number of cubic yard stations of haul between balance points divided by the ordinate of the mass which the yardage is hauled.
What is economical haul?
The limit of economic haul is reached when the cost of haul and the cost of excavation become equal. Beyond that point it is cheaper to waste the cut from one place and to fill the adjacent hollow with material taken from a nearby borrow pit.
What is mass haul diagram in surveying?
A mass haul diagram presents a graphical view of material moved in the proposed design site, displaying balance points, free haul and overhaul regions, and grade points.
What is mass haul curve?
Mass Haul Curve This is a curve representing the cumulative volume of earthwork at any point on the curve, the manner in which earth to be removed. It is necessary to plan the movement of excavated soil of worksite from cuts to fill so that haul distance is minimum to reduce the cost of earthwork.
Grade Point Method
The arrows indicate free haul distance. The number (1) indicates grade points. Freehaul volume is indicated in green (and by the grid between the green areas and the balance line) and overhaul volume is indicated in red.
Balance Point Method
The arrows indicate free haul distance. The number (1) indicates balance points. Freehaul volume is indicated in green and overhaul volume is indicated in red.
