Full Answer
What is a chase wall?
A chase wall is a wall that is built to hide plumbing or other duct work. Chase walls are often added when home remodeling projects require new plumbing routes or vents. Chase walls are built from wallboard or paneling and are installed to match the look of the rest of the walls in the area.
What is a chase in a concrete floor?
A chase is drilled in a concrete floor construction or wall and helps accommodate features like cables and pipes. The width of chase often varies depending on the type or the number of services it will enclose. However, in most cases, the width of a chase will not exceed 3.9 inches (100mm).
What is a plumbing wall/Chase?
Plumbing professionals use these terms quite a bit but it’s rarely defined. Probably the simplest way to explain what a plumbing wall/chase is to say it’s any wall with plumbing piping inside.
How to remove a concrete Chase from a wall?
You may mark the sides of a chase on the wall and use a power drill to cut the waste by drilling several holes. After drilling holes on the wall using a power drill, you can then use a cold chisel and a hammer to remove the concrete and trim the chase’s edges. It is important to inspect the wall and locate pipes and cables already chased in it.
What is Chase in brick wall?
When running cables or pipes up (or along) a masonry wall, the neatest method is to bury (or, in builders terms, chase) them in the wall surface.
What is a wall chase?
A chase in home construction is a vertical space in a wall, which provides an area for pipes or wires to run through. Builders strategically place chases to ensure that cables run together. A chase may run up the wall from the basement to the attic or the upper part of your home.
What is chases in masonry?
Chases can reduce the masonry compressive strength considerably. In general, a reduction of the masonry strength proportional to the reduction of the cross-section area seems to be a reasonable approach in analysing the influence of chases on masonry compressive strength.
What does Chase mean in construction terms?
A chase, as it pertains to new home construction, is a vertical space in a wall that provides an area for pipes or wires to run through. These chases are placed in a strategic way so that cables can be gathered and run together. A chase is simply installed from a single open space to another.
What is a chase cut?
Chase cut edging involves cutting a a channel into your existing tarmac or concrete for your new surface to be tucked into at its perimeter.
How do you fill in a chased wall?
0:2421:03How to Fill Wall Chases, Cracks & Holes - YouTubeYouTubeStart of suggested clipEnd of suggested clipToday will apply to any cracks holes or other repairs that you've got to make to your masonryMoreToday will apply to any cracks holes or other repairs that you've got to make to your masonry plasterboard walls there are obviously lots of ways you can repair your walls.
How do you build a chase wall?
0:033:32How to Build a Chase for Plumbing Pipes | This Old House - YouTubeYouTubeStart of suggested clipEnd of suggested clipBut sometimes they'll have built-ins that will go all the way up to the ceiling all the way up downMoreBut sometimes they'll have built-ins that will go all the way up to the ceiling all the way up down molding on top yes sir yeah and then another option also is to run out soffit.
How deep should a chase wall be?
The document states that, vertical chases shouldn't be deeper than 1/3 leaf of the wall, and horizontal chases shouldn't be deeper than 1/6 of the leaf.
What is the difference between a chase wall and a shaft wall?
Registered User. Dictionary definition: (a continuous recess: Harris) a vertical or horizontal enclosure/recess (of rated or non-rated construction) with which to conceal/route, plumbing, electrical, etc.; shafts tend to be vertical while chases may be either.
What is Chase pipe?
A pipe chase is sometimes also referred to as a plumbing wall. In other words, it is any type of wall that has plumbing piping inside. You may also hear it referred to as a wet wall when in the residential setting or a wet column in the commercial setting.
What is a pipe chase room?
A pipe chase is an enclosed, finished space used to house and conceal pipe runs.
What happens if you chase a wall?
Common sense really – If the chase is too deep it will impair the stability of the wall. If chases are back to back, there is no wall! It must always be remembered that the person doing the electrical work may not be the same person who wants to hang a picture on that wall or put a serving hatch or window in it.
What is a chase tool?
The chasing tool seen in the image below is basically an angle grinder with two parallel blades. The depth of the blades can be set, a hoover hose plugged into the end and off you go.
What do you need to cut a chase line?
When the chase lines are cut you will need a hammer and bolster to chop out the middle but this is really easy as long as the chase blades are not set too far apart. You can also see a hammer and an assortment of chisels in the image. It is now possible to buy a chasing tool which fits onto your electric drill.
How deep should vertical chases be?
The Simple Rules for Cutting Chases in Walls. Vertical chases should not be any deeper than one third of the total wall thickness. In a cavity wall, vertical chases should be no deeper than one third of the thickness of the skin they are being placed in. No chases, horizontal or vertical, should be made back to back.
Can you chase a wall back to back?
No chases, horizontal or vertical, should be made back to back. Horizontal chases should be no deeper than one sixth of the thickness of the wall thickness. In a cavity wall horizontal chases should be no deeper than one sixth of the thickness of the skin they are in. Chases must go from a to b in a straight line and diagonal chases should not be ...
Can you cut chases in walls?
Click here for more information. Cutting chases in walls is not just a question of putting them where you want in any haphazard way. There are guidelines to follow to make the installation of electrical cables as safe as possible for you and anyone else entering your home.
Can you use a chasing tool on an electric drill?
It is now possible to buy a chasing tool which fits onto your electric drill. Once you have cut your chase you can now run in your cables and conduit (ensure that your conduit is the correct width!). Remove the front cap by prising it off and then fix the conduit in place and run your cables down.
