There are some steps below that will show you how to fix f51 error code. First try and reset the washer by unplugging it or killing power to it at your breaker or fuse panel for a few minutes then restore power to it. This will reset the main control board by allowing all the capacitors in the control to drain. Click to see full answer.
How do I fix error code F51 on Whirlpool Cabrio washer?
04/12/2021 · How To Fix F51 Error Code Whirlpool? First, eliminate the technical glitch. You can unplug the machine or turn off the power, and then leave it for a few minutes to dry.
Why does my Kenmore washer have a fault code of F51?
15/06/2020 · There are some steps below that will show you how to fix f51 error code. First try and reset the washer by unplugging it or killing power to it at your breaker or fuse panel for a few minutes then restore power to it. This will reset the main control board by allowing all the capacitors in the control to drain. Click to see full answer.
What does the error code on my washing machine mean?
The Whirlpool brand of washers and dryers. Answer: The F51 fault code on your Cabrio washer indicates that the control board is not detecting the proper spin of the drive motor. By pressing the Pause/Cancel button, you can clear the fault code.
How do I fix error F51 on Whirlpool Cabrio?
Sometimes they are enough to make error f51 disappear forever.Eliminate technical glitch. Unplug the cord or switch off the power and leave the washing machine for a few minutes. ... Take out odd things. ... Find and remove a foreign object. ... Tighten the bolt. ... Rust deposit. ... Wiring failure. ... Defective RPS sensor. ... Control module damage.
What does F 51 mean on my washing machine?
The F51 error may indicate there is a MOTOR ROTOR POSITION SENSOR FAILURE (RPS). The sensor and control board has a connection or fault issue. This error can be cleared by cleaning/reconnecting the sensor OR replacing it.26-Feb-2019
How do you reset a Whirlpool washing machine?
Turn off the washer on the control panel. Unplug the washer for twenty seconds. Turn on the washer. If the process has worked, your washer will now be reset.01-Nov-2021
Why is my Whirlpool washer flashing F?
An F/dL error code indicates a problem with the door lock. The error code will pop up when the door fails to lock. The washer will display the error code after six attempts to lock the door. ... In most cases, you will need to replace the door lock assembly.04-Oct-2021
What does F51 mean on a Whirlpool washer?
The F51 fault code on your Cabrio washer means that the control board is not sensing the proper drive motor spin. It can either be caused by something simple, like an overloaded washer, or a faulty internal component, such as a defective motor rotor position sensor or a wiring problem within your washer.02-Aug-2021
What does F51 mean?
rotor position sensorError code F51 means that the rotor position sensor has a connection error. This connection error causes miscommunication between the sensor and the electronic control.09-Apr-2015
How do I fix a Whirlpool washer error?
Manual ReviewUnplug the Whirlpool washing machine from the mains.Wait for 15-20 minutes while the control unit reboots.Reset the error by pressing the START button (On/Off).Check hatch locking.
How do you manually unlock a Whirlpool washer?
Hold down the "Control Lock" button on your Whirlpool washer for three seconds at the end of the washing cycle. Listen, and when you hear the unlatching sound, the door should open.
How do you do a factory reset on a washing machine?
To reset your washing machine, unplug it from the power outlet. Then, plug the washer cord back into the wall. Finally, open and close the washing machine door six times to send the reset signal to the system components.
How do you clear the error code on a Whirlpool top load washer?
System error code. Press START/PAUSE once to clear the code, then press START/PAUSE again to restart washer. If the code doesn't clear, Contact Us or Schedule Service Online. Hot and cold inlet hoses have been installed incorrectly (reversed).15-Jun-2020
What does F code stand for?
FCODEAcronymDefinitionFCODEForth Code (electrical engineering)
What does El mean on a Whirlpool washer?
If the EL error code appears, unplug the laundry center and check the wire harness connections between the lid lock assembly and the electronic control board. Reconnect any loose wire and repair any broken wires. If the wires are okay, replace the lid lock assembly.
Step One – Reset Your Washer
The first step is to reset your washer. Sometimes simply resetting the washer will remove the F51 error code; this is because it allows the capacitors of the control board to discharge and then start to work correctly again.
Step Three – Check for Foreign Objects
The next step is to check your washer for any items that are stuck in your washing machine that are preventing your washer from working properly. To do this, you will need to turn the power off, empty your washing machine, and then try to move the drum around by hand.
Step Four – Check the Rotor Bolt
If those three steps didn’t solve the problem, then you will have to inspect some of the internal components of your Whirlpool Cabrio washer that might be causing the problem.
Step Five – Check for Corrosion
The next step is to check for corrosion within your washing machine drum. The washer drum should be able to rotate around smoothly on its shaft, but sometimes people use too much detergent in their washing machines, and this can cause rust to develop, which stops the drive system from working properly, resulting in the F51 error code appearing.
Step Six – Check the Wiring
Sometimes the F51 error code can appear if you have a problem with your washing machine’s wiring – specifically when the connection between the motor rotor sensor and the control board is faulty.
Step Seven – Replace the Control Board
If you still haven’t found the source of the problem, the last component to check is the control board. However, the control board is very difficult to check, so your best option is to just replace it. The problem is it’s quite an expensive repair to do, so you might be best off purchasing a new washing machine instead of fixing your current one.
Why does my washing machine drum get stuck?
Ideally, a proper functioning drum should rotate smoothly on its shaft. However, it may get stuck as it rotates due to corrosion. When this happens, the RPS sensor of your washing machine sends a signal to the appliance’s control board. The soapy stains that appear as a result of excess amount of conditioner and detergent also contribute towards this problem. Therefore, the drum loses its capacity to rotate uniformly, causing friction in the washer’s drive system and leading to the appearance of fault code F51 o the washer’s digital display screen. Follow this process to identify the problem:
What to do if your washer is stuck?
If your washer’s drum is stuck or it rotates with a lot of effort or makes a rattle, removes to examine the shaft. It would help if you would also inspect for corrosion. In case there is dust and rust, remove all the rust and dirt. However, if the damage cannot be repaired, install a new component in your washer.
Why does my washing machine have a F51?
Your washer may display the F51 because of faulty wiring, where the connection between the washer’s control board and the motor sensor is defective. Follow these steps to examine this problem. Unplug your washing machine from its power source, drainage system, and water supply.
What to do if there is no continuity on washer?
If there is no continuity, change your washer’s lower harness. You also need to check for continuity in the contact between the drive motor connector and points of your motor connector (P5). If there is no continuity, you need to renew the cable. If there is continuity, you need to reinstall an electric motor.

Step One – Reset Your Washer
- The first step is to reset your washer. Sometimes simply resetting the washer will remove the F51 error code; this is because it allows the capacitors of the control board to discharge and then start to work correctly again. To reset the washer: 1. Try to reset the washer by pressing down the “Pause/Cancel” button. 2. If that doesn’t work, unplug the cord or switch off the power and leav…
Step Two – Check That The Washer Isn’T Overloaded
- If a simple reset didn’t solve the problem, the next step is to ensure that your washer isn’t overloaded with too many clothes. When your washer is overloaded, the rotor cannot spin the washer drum around correctly, and an F51 error code will result. To check if your washer is overloaded, make sure that it isn’t overly full (more than 80% full to the top), and if it is, remove s…
Step Three – Check For Foreign Objects
- The next step is to check your washer for any items that are stuck in your washing machine that are preventing your washer from working properly. To do this, you will need to turn the power off, empty your washing machine, and then try to move the drum around by hand. If it rotates around very tightly, this is a good sign that something is blocking between the bottom of the drum and t…
Step Four – Check The Rotor Bolt
- If those three steps didn’t solve the problem, then you will have to inspect some of the internal components of your Whirlpool Cabrio washer that might be causing the problem. The first component to check is the rotor bolt, which helps to secure the rotor in place. When the bolt is loose, your washer might malfunction. To check the rotor bolt, you need to: 1. Turn the power of…
Step Five – Check For Corrosion
- The next step is to check for corrosion within your washing machine drum. The washer drum should be able to rotate around smoothly on its shaft, but sometimes people use too much detergent in their washing machines, and this can cause rust to develop, which stops the drive system from working properly, resulting in the F51 error code appearing. To check this out, you n…
Step Six – Check The Wiring
- Sometimes the F51 error code can appear if you have a problem with your washing machine’s wiring – specifically when the connection between the motor rotor sensor and the control board is faulty. To check the wiring, you need to: 1. Ensure the power is still turned off to the washer. 2. If you haven’t already, you will need to remove the side panels of the washing machine and lay it d…
Step Seven – Replace The Control Board
- If you still haven’t found the source of the problem, the last component to check is the control board. However, the control board is very difficult to check, so your best option is to just replace it. The problem is it’s quite an expensive repair to do, so you might be best off purchasing a new washing machine instead of fixing your current one. If you do decide to replace the control boar…
